FELLOWS 64Y Vertical Gear Shaping Machine
FELLOWS 64Y Vertical Gear Shaping Machine
Contact us for price
Location:Malaysia
or
Call +60194711264
Specifications
| Manufacturer | Fellows |
| Model | 64Y |
| Condition | Used |
| Stock Number | 1036 |
| Max. Swing | 48" |
| Cutter Spindle | 4-1/2" |
| Max. Ext. Pitch Spur Diameter | 36" |
| Max. Ext. Pitch Helical Diameter | 36" |
| Max. Int. Pitch Spur Diameter | 43" |
| Max. Int. Pitch Helical Diameter | 43" |
| Max. Diameter Pitch, Spur | 4 |
| Max. Stroke Int. & Ext. | 7" |
| Riser | 6" |
| Hole in Work Spindle | 5-7/8" |
| Distance Max. from the Cutter Spindle to Work Spindle | 12-1/2" |
