Dahlih DCM2213 Double Column Machining Center Year 2008 with LM Guide and 4th Axis
Dahlih DCM2213 Double Column Machining Center Year 2008 with LM Guide and 4th Axis
Contact us for price
Location:Malaysia
or
Call +60194711264
Specifications
| Manufacturer | Dahlih |
| Model | DCM2213 |
| Year | 2008 |
| Condition | Used |
| Stock Number | 0828 |
| Table working surface | 2500 × 1350 mm |
| Max. table load | 4000 kg |
| Longitudinal travel (X) | 2200 mm |
| Cross travel (Y) | 1300 mm |
| Headstock travel (Z) | 800 mm |
| Distance between columns | 1400 mm |
| Cutting feed | 1 – 10,000 mm/min |
| Spindle speed | 60 – 6,000 rpm |
| Spindle bearing diameter | Ø100 mm |
| Tool changer | 40 tools |
| Tool holder | BT50 |
| Max. tool length | 400 mm |
| Max. tool weight | 15 kg |
| Floor space | 4230 × 8500 mm |
| Net weight | 23,000 kg |
| CNC controller | FANUC |
