MaxSee P36 Die Sinking EDM Year 2007
MaxSee P36 Die Sinking EDM Year 2007
Contact us for price
Location:Malaysia
or
Call +60194711264
Specifications
| Manufacturer | MAX SEE |
| Model | P36 |
| Year | 2007 |
| Condition | Used |
| Stock Number | 0813 |
| X-axis travel | 400 mm |
| Y-axis travel | 300 mm |
| Z-axis travel | 185 mm |
| U-axis travel | 230 mm |
| Work table size | 650 × 350 mm |
| Max. workpiece dimensions (flush) | 1000 × 600 × 330 mm |
| Max. workpiece weight | 1000 kg |
| Max. electrode weight | 120 kg |
| Distance from work table to electrode plate | 140 – 555 mm |
| Max. machining current | 50 A |
| Power input | 4.5 KVA |
| Max. dielectric level | 280 mm |
| Dielectric unit capacity | 310 L |
| Filter | 2 pcs |
| Machine weight | 2350 kg |
| Machine dimensions (L × W × H) | 2800 × 1750 × 2480 mm |
