Myday 1600x4000 CNC Lathe Year 2013
Myday 1600x4000 CNC Lathe Year 2013
Contact us for price
Location:Malaysia
or
Call +60194711264
Specifications
| Year | 2013 |
| Condition | Used |
| Stock Number | 0713 |
| Center Height | 800 |
| Swing over Bed | 1580 |
| Swing over Cross Slide | 1140 |
| Dq7 | Fot |
| Width of Bed | 800 |
| Distance Between Centers | 4000 |
| Z-axis Travel, Max | 1750-9750 |
| X-axis Travel, Max | 800 |
| Z-axis Ball Screw | Ø80* |
| X-axis Ball Screw | Ø50 |
| Quill Diameter | Ø200 |
| Quill Taper | MT7 |
| Quill Travel | 300 |
| Controller | Fanuc 0i-TD |
| Manual Chuck 4 Jaw | 1000mm |
| Through Spindle Hole | Diameter 230mm |
| Tools capacity | 8 stations |
